Location:  Home -> Products  ->  Equipment  ->  Automatic Taping Equipment  ->  Tray to Tray Automatic Taping Machine  ->  Tray to Tray Automatic Taping Machine TTT-100

【Origin Pic】

Tray to Tray Automatic Taping Machine TTT-100 The equipment features a dual robotic arm handling structure, with automatic loading from the tray. After calculating the row and column spacing using PLC, the robotic arm picks up the components. After undergoing image inspection, defective components are discarded, while the acceptable components are placed into a new tray and arranged. It is suitable for batch processing of ICs, modules, hardware components, and other materials, and it can perform functions such as tray arrangement and inspection.

  • Detail

  • Product Specs

  • Features&Benefits

  • Options

  • Related Supplies

● Placement Speed:UPH 1500~5000
● Production output:12~56mm
● Dimensions: D 1100mm x W 1000mm x H 1550m
● Weight：350KG

Specification:TTT-100

● The equipment allows for the conversion between new and old trays. It features a track clamp-type cavity that ensures stable control and easy adjustment
● The servo motor ensures precise tape pulling
● The blade head allows precise adjustment, with fine-tuning of the inner and outer heat sealing blades using micro-heads to achieve precise adjustment of the sealing line position within ±0.1mm, resulting in a more aesthetically pleasing seal
● Dual independent PID temperature control ensures accurate and stable temperature control
● Automatic cutting and automatic feeding from the vibration feeder. Parameters and production quantities can be saved even when power is lost.

SRM-0101

● Vision Inspection
● Empty pocket detector
● Laser Marking
● Upgrading Feeding System(tube/bowl/tray input)
● Dimensional Inspection
● 3D BGA inspection
●Electrical Performance Testing

● Manual Taping Machine
● Peel force tester
● Aluminum foil bag vacuum packaging machine
● Carrier tape, cover tape, reel
